IC122055

The perfect balance of power, combining a pure sine wave inverter with a smart battery charger

2000W / 55A Inverter-Charger

High Frequency Series

Combines KISAE’s renowned true sinewave inverter technology with its smart battery charger technology, resulting in the ability to run household appliances, electronics and power tools in your truck, boat or RV and properly recharge your batteries.

Features include:

  • True sinewave output to run motor loads and sensitive electronics without hum or buzz.
  • Multi-stage charger to charge your deep-cycle batteries quickly and efficiently to manufacturer’s recommendations.
  • Integrated transfer switch to switch seamlessly from shore power to battery power.
  • Ideal for running appliances & consumer electronics the way they were designed to be.

Connect With Us

Get Pluggin In

IC122055 Product Details

  • Overview
  • Specs
  • Downloads

Features And Benefits

  • High frequency design with high surge capability to start demanding loads.
  • True sinewave output will run heavy-duty motor loads and  entertainment systems flawlessly.
  • Low battery shutdown to prevent total battery discharge
  • Detachable remote panel provides vital system information.
  • Over temperature shutdown.
  • Mounting brackets and high quality DC connectors for simple installation.
  • Approved to UL, CSA, and European regulatory standards.
  • Silent operation.
  • Compact size for easy storage.
  • Wall-mountable.

Dimensions (L x W x H):

IC122055: 18.8” x 9.1” x 4.5” (477.5 x 231 x 114mm)

Weight:

IC122055: 15.9 lbs. / 7.2 Kg

Power (Continuous) 2000W
Power (Peak) 4000W
Voltage/Frequency 120VAC / 60 Hz
Current 16.6A
Waveform True Sine Wave (<3% THD)
Peak Eciency 90%
AC Receptacle NEMA 5-20 GFCI
5V USB Output 2.1Vdc
Voltage (nominal) 12.5Vdc
Operation Range 10.5 – 15.5Vdc
Inverter Standby Current < 1.5A
Input Undervoltage Shutdown 10.5/11.0Vdc
Inverter Overvoltage Shutdown 15.5Vdc
Digital Remote Panel Detachable (included)
Digital Display (LED) Input Voltage, Output Power, Warning, Error Code
Charger Voltage Range 13.5 – 14.4V
Float Voltage Range 13.4 – 13.8V
Charger Current 55A
Charger Battery Type GEL, Flooded, AGM, Lithium, Programmable, Power Supply
AC Input Voltage/Frequency 120VAC / 60Hz
Transfer Time <30ms
Transfer Relay Rating 30A
Markings cETLus
Conformance UL & CSA Standards
Weight 14.5 lbs.
Dimension 18.8 x 9.1 x 4.6”
Ignition Start Module ISRM01
Battery Temperature Sensor BTS 10K (For battery charging voltage adjustment)
Model IC-122055
Model IC-122055
